Gulf ATF DX III H
Extra high performance Automatic Transmission Fluid
Gulf ATF DX III H is an extra high performance automatic transmission fluid for all General Motors and Ford automatic transmissions requiring DEXRON®-III (including the new DEXRON® III H specification) or MERCON® quality fluids respectively. The modern additive technology and specially selected base oils used in this oil provide superior thermo-oxidative stability, corrosion & rust protection, foam control, seal compatibility, friction durability and low temperature fluidity. It is designed to exceed the performance requirements of General Motors DEXRON® III H and Ford MERCON® specifications.
Features & Benefits
- Superior thermo-oxidative stability, wear protection and resistance to chemical deterioration can provide longer fluid and component life.
- Controlled frictional properties lead to smooth shift performance, efficient transmission of power and prevent shudder.
- Extremely high Viscosity index ensures adequate lubrication in both high operating & low starting temperatures.
- Provides excellent protection against rust and corrosion.
- Effective foam control leads to smooth & lasting shift feel and reduces fluid loss.
- Improved low temperature fluidity leads to easy pumping in the hydraulic circuits.
- Better seal compatibility ensures longer seal life and reduces possibility of oil leakage.
Applications
- Recommended for all vehicles of Ford requiring MERCON® quality fluids and General Motors requiring DEXRON®-III H quality fluids.
- Being back serviceable, also recommended for automatic transmissions requiring General Motors DEXRON® III , DEXRON® II E or DEXRON® II D fluids and also for imported cars like Audi, Honda, Mazda, Nissan, Opel, Renault, Toyota and Volkswagen where such fluids are specified.
Specifications, Approvals & Typical Properties
Meets the following Specifications |
||
|
General Motors DEXRON III H |
X |
|
|
Ford MERCON |
X |
|
Has the following Approvals |
||
|
Volvo Transmission Oil 97341 approval |
X |
|
|
ZF TE-ML 04D, 14A (ZF Approval Number: ZF000078) |
X |
|
|
MAN 339 Typ L1 and MAN 339 Typ Z1 |
X |
|
|
Typical Properties |
||
|
Test Parameters |
ASTM Method |
Typical Values |
|
Viscosity @ 100 C, cSt |
D 445 |
7.4 |
|
Viscosity Index |
D 2270 |
178 |
|
Flash Point, C |
D 92 |
216 |
|
Pour Point, C |
D 97 |
-48 |
|
Brookfield Viscosity @ -40 0C, cP |
D 2983 |
18456 |
|
Density @ 15C, Kg/l |
D 1298 |
0.857 |
