Gulf Harmony ZF 46

High performance ashless anti-wear hydraulic oil

Gulf Harmony ZF series are high performance ashless anti-wear hydraulic oils developed to provide excellent performance in hydraulic systems operating under moderate to severe conditions. They are formulated with an advanced ashless anti-wear technology and select base oils to provide reduced environmental impact in case of an accidental release into the environment. They exhibit excellent anti-wear property, thermo-oxidative stability, foam control and water separation properties. They are available in ISO 10 through ISO 100 viscosity grades and exceed the performance requirements of global industry standards viz. DIN 51524 Part 2-HLP, AFNOR NFE 48-603 (HM) & ISO 11158 HM and majority of the international OEMs viz. Denison, FIVES CINCINNATI (Former MAG IAS, LLC) and Eaton (Vickers).

Features & Benefits

  • Excellent thermo-oxidative stability controls the formation of sludge & varnish and improves oil life
  • Exceptional anti-wear property results in longer pump and component life and reduces costs
  • Superior demulsibility helps in faster separation of water from oil and resists formation of emulsions
  • Advanced ashless additive technology reduces environmental impact in case of accidental spillage
  • Special rust & corrosion inhibitors protect multi-metallurgy components even in presence of moisture
  • Rapid air release property minimises chances of pump cavitation leading to trouble free operations
  • Compatible with multi-metals and sealing materials commonly used in hydraulic systems

Applications

  • Hydraulic systems operating under moderate to severe conditions in mobile and industrial service even in environmentally sensitive applications
  • Mobile hydraulic fluid power transmission systems and general machine lubrication
  • Older design hydraulic pumps containing silver or silver-plated parts

Specifications, Approvals & Typical Properties

ISO Viscosity grades

10

15

22

32

46

68

100

Specifications

DIN 51524 Part 2-HLP

X

X

X

X

X

X

X

AFNOR NFE 48-603 (HM), ISO 11158 HM

X

X

X

X

X

X

X

FIVES CINCINNATI (Former MAG IAS, LLC)







P-68

P-70

P-69



Eaton (Vickers) M-2950-S, I-286-S







X

X

X



Has the following Approvals

Denison HF-0, HF-1, HF-2







X

X

X



Typical Properties

Test Parameters

ASTM Method

Typical Values

Viscosity @ 40 C, cSt

D 445

10.1

15.1

22.2

31.2

45.9

68.3

98.3

Viscosity Index

D 2270

97

97

98

100

100

99

97

Flash Point, C

D 92

136

164

186

202

210

218

230

Pour Point, C

D 97

-30

-24

-24

-24

-24

-24

-12

Density @ 15C, Kg/l

D 1298

0.847

0.858

0.865

0.87

0.874

0.881

0.886

Rust Test

D 665A/B

Pass

Pass

Pass

Pass

Pass

Pass

Pass

Emulsion Test
30 minutes max

@ 54 oC

D 1401

Pass

Pass

Pass

Pass

Pass

Pass

-

@ 82 oC

-

-

-

-

-

-

Pass

Foam Test, foam after 10 minutes of settling for all sequences

D 892

Nil

Nil

Nil

Nil

Nil

Nil

Nil

Turbine Oil Stability Test, hrs

D 943

2000+

3000+

2500+

2000+

FZG, fail load stage, minimum

DIN 51354 Part II

-

-

-

11

11

11

11
