Gulf Harmony ZF-HVI Plus 46

Supreme quality, ashless high viscosity index hydraulic oil for extreme temperature ranges

Gulf Harmony ZF-HVI Plus series are supreme quality ashless anti-wear hydraulic oils specially developed for applications subjected to wide range of temperature or where small viscosity change with fluctuating temperature is needed. They are formulated with severely hydroprocessed Group II base oils, a highly shear stable polymer and an advanced ash-less additive system to provide reduced environmental impact in case of an accidental spillage. Their outstanding thermo-oxidative stability and low & high temperature performance allows for extended service life. They provide excellent anti-wear property, rust & corrosion protection, water separation & air-release properties and hydrolytic stability to reduce breakdowns and help improve production capacity. They exceed the performance requirements of global industry standards viz. DIN 51524 Part 3 HVLP, AFNOR NFE 48-603 (HV) & ISO 11158 HV and majority of the international OEMs viz. Poclain, Hitachi, FIVES CINCINNATI (Former MAG IAS, LLC), Eaton & Denison

Features & Benefits

  • Outstanding thermo-oxidative stability reduces deposit formation, improves pump performance and gives extended oil & filter change intervals
  • Extremely high viscosity index assures equipment protection at cold start-up temperatures as well as at high operating temperatures
  • Excellent shear stability minimises viscosity loss over time and exhibits “stay-in-grade” performance under high shear conditions
  • Excellent demulsibility helps in faster separation of water from oil and resists formation of emulsions
  • Special rust & corrosion inhibitors protect multi-metallurgy components against negative effects of moisture presence in the system
  • Rapid air release property minimises chances of pump cavitation and thus prevents component damage, reduces vibration and maintains efficiency especially in modern hydraulic systems where sump sizes are becoming smaller
  • Offers long term hydrolytic stability and yellow metal compatibility in presence of water
  • Compatible with multi-metals & most sealing materials used in hydraulic systems

Applications

  • Hydraulic and power transmission systems subjected to a wide range of ambient & operating temperatures even in environmentally sensitive applications
  • Applications requiring extended oil change intervals
  • Critical hydraulic systems such as high accuracy numerically controlled machine tools and those employing close clearance servo valves
  • Hydraulic systems of excavators, cranes and hydrostatic drives subjected to most severe outdoor operating conditions
  • Hydraulic systems operating under high pressures and requiring high degree of load carrying capability and anti-wear protection

Specifications, Approvals & Typical Properties

ISO Viscosity grades

15

32

46

68

100

Meet the following Specifications

DIN 51524 Part 3 HVLP

X

X

X

X

X

AFNOR NFE 48-603 (HV)

X

X

X

X

X

ISO 11158 HV

X

X

X

X

X

Denison HF-0, HF-1, HF-2



X

X

X



FIVES CINCINNATI (Former MAG IAS, LLC)



P-68

P-70

P-69



Eaton (Vickers) M-2950-S



X

X

X



Eaton (Vickers) I-286-S



X

X

X



Poclain







X

X

Hitachi





X





Typical Properties



Test Parameters

ASTM Method

Test Values

Viscosity @ 40 C, cSt

D 445

15.1

31.5

46.7

68.6

99.4

Viscosity Index

D 2270

148

147

145

148

145

Flash Point, C

D 92

201

214

222

232

242

Pour Point, C

D 97

-42

-39

-33

-30

-27

Density @ 15C, Kg/l

D 1298

0.853

0.853

0.855

0.858

0.861

Rust Test

D 665A/B

Pass

Pass

Pass

Pass

Pass

Emulsion Test

30 minutes max

@ 54 oC

D 1401

Pass

Pass

Pass

Pass

-

@ 82 oC

-

-

-

-

Pass

Foam Test, foam after 10 minutes of settling for all sequences

D 892

Nil

Nil

Nil

Nil

Nil

Turbine Oil Stability Test, hrs

D 943

-

-

6500+

6000+

5000+

FZG, fail load stage, minimum

DIN 51354 Part II

-

-

11

11

11
