Gulf MERCON® V ATF

Premium Automatic Transmission Fluid

Gulf MERCON® V ATF is premium automatic transmission fluid for all Ford automatic transmissions requiring MERCON® V quality fluids and a broad range of vehicles from various OEMs. This synthetic automatic transmission fluid with its advanced additive technology offers superior and well balanced performance and provides excellent oxidation resistance, wear protection, friction durability and seal compatibility. It is approved as service fill fluid against Ford MERCON® V (license number: M5090104) specifications. It also meets the performance requirements of Allison C-4 and JASO 1-A specifications and is suitable for use in various applications as listed in the table.

Features & Benefits

  • Excellent thermo-oxidative stability, wear protection and resistance to chemical deterioration leads to longer fluid and transmission life
  • Controlled frictional properties lead to smooth shift performance, efficient transmission of power and eliminates shudder often encountered in transmissions with continuously slipping torque converters
  • Extremely high Viscosity index ensures adequate lubrication in both high operating & low starting temperatures
  • Provides excellent protection against rust and corrosion
  • Superior foam control leads to smooth & lasting shift feel and reduces fluid loss
  • Improved low temperature fluidity leads to easy pumping in the hydraulic circuits
  • Superior seal compatibility ensures longer seal life and reduces possibility of oil leakage

Applications

  • Recommended for & meets the warranty requirements of all vehicles of Ford requiring MERCON® V quality fluids.
  • Also recommended for Allison Powershift transmissions or other torque converters requiring Allison C-4 quality fluids.
  • Also suitable for various automatic transmissions as listed in the table.

Note : Not suitable for use in Continuously Variable Transmissions (CVT), Dual Clutch Transmission (DCT), Ford Type F/G, Daimler MB 7 speed (NAG 2), ZF 6 Speed



Suitable for Use:

Suitable for Use:

OEM

ATF Specification

OEM

ATF Specification

Aisin Warner

JWS 3309

JATCO

JATCO 3100 PL085 (Idemitsu K17 -
Jaguar X Type 2001-2005)

Allison

C-4

KIA

SP-II/ SP-III

Audi

G 052 025-A2, G-052-162-A1

MAN

339F, 339 V1, 339 V2, 339 Z1, 339 Z2, 339 Z3

BMW

(AE) LT 71141 ZF 5 Speed, 7045E (3 Series), ETL-8072B
(BMW 5 Series), LA2634

Mazda

ATF-M III, ATF-MV

Chrysler

ATF +3, ATF +4

Mitsubishi

Diamond SP-II, SP-III

Daimler

MB 236.1, MB 236.2, MB 236.5, MB 236.6,
MB 236.7, MB 236.9, MB 236.10
(Daimler NAG-1 for MB 5 Speed 1996-2006),
MB 236.11 (LT 71141)

Nissan

Matic-D, J, K, N402 (JATCO FWD in
Nissan, Rover 800, VW Polo)

Subaru

ATF-HP

Ford

MERCON, MERCON V

Toyota

T-III, T-IV

General Motors

DEXRON, DEXRON-II/ IID, DEXRON-III G/H

Voith

55.6335.XX (G607), 55.6336.XX (G1363)

Honda

ATF-Z1

Volkswagen

VW G 052 025-A2, VW G-052-162-A1

Hyundai

SP-II/ SP-III

Volvo

Volvo 97340

JASO

JASO 1-A

ZF

ZF TE-ML 03D, 04D, 09, 14A, 14B, 14C, 16L, 17C

Specifications, Approvals & Typical Properties

Meets the following Specifications

Gulf MERCON V ATF

Ford MERCON,

x

Allison Transmission Division's C-4

x

JASO 1-A

x

Has the following Approvals

Ford MERCON V (license number: M5090104)

x

Typical Properties

Test Parameters

ASTM Method

Typical Values

Viscosity @ 100 C, cSt

D 445

7.2

Viscosity Index

D 2270

180

Flash Point, C

D 92

204

Pour Point, C

D 97

-51

Brookfield Viscosity @ -40 0C, cP

D 2983

12000

Density @ 15C, Kg/l

D 1298

0.851

MERCON® is a registered trademark of Ford Motor Company
DEXRON® is a registered trademark of General Motors Corporation
